Heavy Duty Swivel Top Plate Caster with Top Lock Brake and Bolt on Swivel Lock and 5 Inch Rubber on Metal Wheel with Ball Bearings - 400 lbs. Capacity/Caster - Service Caster Brand
4.5 (108 items)
Limited Time SaleUS$38.69 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 222915811 | Release Date | 2026/05/09 | List Price | US$25.80 | Model Number | 222915811 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Listing is for one (1) Service Caster Series #30 swivel caster with a 5" diameter by 2" wide rubber on cast iron wheel and maintenance free precision ball wheel bearings with a side lock brake & bolt on swivel lock capable of supporting 400 lbs./caster. When searching for a reliable and durable solution for medium and heavy duty projects, consider Service Caster’s Series 30 moldon rubber on cast iron wheel casters. The Service Caster Series #30 is ideal for material handling, carts, equipment, and shop projects. The moldon rubber tread performs especially well on hard surfaces such as concrete, tile, and wood, while the cast iron core wheel stands up to heavier loads with a stable and secure roll. Finely crafted with double ball bearing heat treated raceways, these versatile casters are ideal for a wide range of applications, such as dollies, platform trucks, warehouse carts and freight terminals. Or ensure a smooth and secure ride for food service carts, hotel housekeeping carts, and industrial and commercial equipment. Even drywall carts, welding carts, and wall panel carts will be ready to roll on the Series 30, keeping you moving forward. Service Caster is unsurpassed in quality, reliability, and excellent customer service. Count on us to move you forward.
- These Service Caster Series #30 Rubber on Cast Iron casters offer various wheel sizes and mounting heights: 4” wheel: 5-5/8” mounting height; 5” wheel: 6-1/2” mounting height; 6” wheel: 7-1/2” mounting height; 8” wheel: 9-1/2” mounting height.
- Weight Capacity: 4": 400 lbs Capacity/Caster, 5": 400 lbs Capacity/Caster, 6": 450 lbs. Capacity/Caster, and 8": 500 lbs Capacity/Caster
- Top plate measures at 4" x 4-1/2" with a bolt hole pattern of 2-5/8" x 3-5/8" to 3" x 3" and can either be bolted or welded on.
- Brake options include a top lock brake (TLB), or a total lock brake (TTL). The top lock brake (TLB) places a positive locking force against the wheel tread locking the wheel only. The total lock brake (TTL) also places a positive locking force against the wheel tread, but the total lock brake (TTL) simultaneously locks the wheel and the swivel for a complete stationary position.
- Find other wheel materials, sizes and all Service Caster products at our Amazon Storefront. Click on the “by Service Caster” link above the main title on any Service Caster page listing.
| UPC | 011586572607 |
|---|---|
| ASIN | B08PVZ7JYT |
| Size | 5" Wheel |
| Color | Swivel - Brake & Bolt on Swivel Lock - Black |
| Brand Name | Service Caster |
| Unit Count | 1.0 Count |
| Manufacturer | Service Caster |
| Model Number | Series #30 |
| Material Type | Rubber on Cast Iron |
| Exterior Finish | Bright Zinc Plated Finish |
| Manufacturer Part Number | SCC-30CS520-RSB-TLB-BSL |
| Compatible with Vehicle Type | Truck |
